Product Description
DJI | M30 Dock Version | Automated Drone Hangars | Industrial Drone Solution
DESCRIPTION
The DJI M30 Dock Version Automated Drone Hangar revolutionizes drone operations with fully automated and remote-controlled functionality. Designed for the DJI Matrice 30 Series, the dock integrates seamlessly with DJI FlightHub 2 to perform scheduled missions, manage data, and operate autonomously 24/7. Its TEC air cooling system facilitates fast battery charging, ensuring minimal downtime and increased operational efficiency.
Engineered for challenging environments, the dock features IP55 weather resistance and robust lightning protection, making it suitable for diverse industries like agriculture, inspection, and emergency response. Its lightweight and compact design allow for quick setup, requiring only power, internet access, and basic ground fixation.
The dock also offers wide-area coverage with the Matrice 30 Series, boasting up to 40 minutes of flight time and a maximum mission radius of 7 km. With advanced sensors, including wind speed and rainfall detection, and integration with DJI Pilot 2, the DJI M30 Dock Version ensures safe and reliable operations in any condition.
Key Features
- Autonomous Drone Operations: Fully automated landing, charging, and takeoff.
- Durable All-Weather Design: Built to withstand extreme temperatures, dust, and water exposure.
- Advanced Sensors: Monitors environmental conditions with wind speed, rainfall, temperature, and humidity sensors.
- Integrated Security Camera: Provides a 1080p live feed with a 180° field of view.
- Easy Setup: Lightweight and compact for hassle-free deployment.
Detailed Specification
General Specifications
| Feature | Details |
|---|---|
| Product Name | DJI Dock |
| Weight | 90 kg |
| Dimensions (Cover Open) | 1,675 × 895 × 530 mm (L × W × H) |
| Dimensions (Cover Closed) | 805 × 895 × 840 mm (L × W × H) |
| Input Voltage | 100-240 VAC, 47-63 Hz |
| Max Input Power | 1,500 W |
| Operating Temperature | -35°C to 50°C (-31°F to 122°F) |
| Ingress Protection Rating | IP55 |
| Max Operating Radius | 7,000 m |
| Max Operating Altitude | 4,000 m |
Charging Performance
| Feature | Details |
|---|---|
| Output Voltage | 18 to 26.1 V |
| Charging Time | 25 minutes (10% to 90% battery) |
Video Transmission
| Feature | Details |
|---|---|
| Transmission System | O3 Enterprise |
| Operating Frequency | 2.4000-2.4835 GHz, 5.725-5.850 GHz |
| Antenna Configuration | 4 antennas, 2T4R |
Backup Battery
| Feature | Details |
|---|---|
| Battery Type | Lead-acid |
| Capacity | 12 Ah |
| Battery Life | > 5 hours |
Air Conditioning System
| Feature | Details |
|---|---|
| Type | TEC Air Conditioning |
| Operating Voltage | 48 VDC |
Sensors
| Type | Supported |
|---|---|
| Wind Speed Sensor | Yes |
| Rainfall Sensor | Yes |
| Temperature Sensor | Yes |
| Humidity Sensor | Yes |
In Package
- 1x DJI Dock
- 1x Integrated Security Camera
- 1x Backup Battery
- 1x TEC Air Conditioning System
- 1x Lightning Protection Unit
